DT Large Flow Full Cone Nozzle

Categories: Full Cone Nozzles, Spray Nozzles

Spray Angle: 60°, 90°, 120°

Connection: 1-1/2″, 1-1/4″, 1", 2-1/2″, 2", 3", 3/4", 4", 6″, BSPT, NPT

Max Pressure(bar): 7

Min Pressure(bar): 0.2

Max Flow(L/min): 8180

Spray Angle: 60°, 90°, 120°
Pipe thread: BSP, NPT
Pipe size: 3/4 – 6
Pressure: 0.2 – 7 Bar
Flow rate: 6.25 – 8180 L/min

Applications

Flue gas desulfurization and dust removal, ship flue gas desulfurization, power plant flue gas desulfurization, waste gas washing, tail gas treatment, gas cooling, dust removal, fire prevention and fire extinguishing, etc.

Spray Angle	60°, 90°, 120°
Connection	1-1/2″, 1-1/4″, 1", 2-1/2″, 2", 3", 3/4", 4", 6″, BSPT, NPT
Max Pressure(bar)	7
Min Pressure(bar)	0.2
Max Flow(L/min)	8180
